Air Compressor

TE-AC 230/24

Item no.: 4010460 EAN: 4006825594478
  • Oil lubrication contributes to long life
  • Oil level check through inspection window
  • The 24l tank offers plenty of air reserves
  • Applications up to 8 bar can be set using the pressure reducer
  • Pressure gauge, quick-release coupling for controlled pressure
  • Pressure gauge for uncontrolled pressure
  • Large wheels and holding bar for easy transport
  • Vibration-absorbing foot ensures stability
  • The drain plug enables user-friendly maintenance
  • 10 year warranty against rusting through of the tank
  • Non-return valve, safety valve
See more information
Show less information
einhell-expert-air-compressor-4010460-productimage-999
Article description

The TE-AC 230/24 compressor is an efficient and robust endurance runner for high requirements. The high-quality components and oil lubrication ensure a very long service life. The oil level can be conveniently checked visually through the inspection window. The working pressure of up to 8 bar can be set to many applications using the pressure reducer. Suficient reserves of compressed air for every application are held ready by the 24 liter tank. The controlled working pressure of the TE-AC 230/24 can be conveniently read off on the pressure gauge and reduced by one quick-release coupling. A pressure gauge is available for checking the uncontrolled tank pressures. The practical drain plug for letting off the condensate enables user-friendly maintenance. A non-return valve and a safety valve ensure the safe operation of the TE-AC 230/24, while the large wheels and holding bar enable easy transport. Complete with a 10-year guarantee against rusting through of the solid, long-lasting tank.

See more information
Show less information

Technical details

Mains supply
230 V | 50 Hz
Max. engine power
1500 W 2 PS
Motor speed
2850 min^-1
Pump speed
2850 min^-1
Suction capacity
230 L/min
Output power at 0 bar
132 L/min
Output power at 4 bar
102 L/min
Output power at 7 bar
83 L/min
Max. operating pressure
8 bar
Tank volume
24 L
Number of cylinders
1 Pieces
Sound pressure level; Lpa
72 dB (A)
Sound power level; Lwa
94 dB (A)
